THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA.
Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 4 Series Coupé.
THE 4 THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA.
Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 4 Series Coupé.
TECHNICAL DATA OF THE BMW 4 SERIES COUPÉ.
Select model
- BMW 420i Coupé
- BMW 420i xDrive Coupé
- BMW 430i Coupé
- BMW 430i xDrive Coupé
- BMW M440i Coupé
- BMW M440i xDrive Coupé
- BMW 420d Coupé
- BMW 420d xDrive Coupé
- BMW 430d xDrive Coupé
- BMW M440d xDrive Coupé
No search result found. Please try another input
| Unladen weight EU in kg | 1,600 |
|---|---|
| Max. permissible weight in kg | 2,015 |
| Permitted load in kg | 490 |
| Permitted axle load front/rear in kg | 970/1,120 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 135 (184)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 300/1,350-4,000 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 240 |
|---|---|
| Acceleration 0–100 km/h in s | 7.5 |
| Combined in l/100 km | 7.1-6.3 |
|---|---|
| CO2 combined emissions in g/km | 162-143 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,665 |
|---|---|
| Max. permissible weight in kg | 1,080 |
| Permitted load in kg | 490 |
| Permitted axle load front/rear in kg | 1,020/1,130 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 135 (184)/5,000-6,500 |
| Engine torque (Nm) at 1/min | 300/1,350-4,000 |
| Compression ratio : 1 | 11.0 |
| Top speed in km/h | 238 |
|---|---|
| Acceleration 0–100 km/h in s | 7.8 |
| Combined in l/100 km | 7.5-6.6 |
|---|---|
| CO2 combined emissions in g/km | 170-151 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,620 |
|---|---|
| Max. permissible weight in kg | 2,030 |
| Permitted load in kg | 485 |
| Permitted axle load front/rear in kg | 980/1,120 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 180 (245)/4,500-6,500 |
| Engine torque (Nm) at 1/min | 400/1,600-4,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 5.9 |
| Combined in l/100 km | 7.4-6.6 |
|---|---|
| CO2 combined emissions in g/km | 168-149 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,680 |
|---|---|
| Max. permissible weight in kg | 2.095 |
| Permitted load in kg | 490 |
| Permitted axle load front/rear in kg | 1,030/1,130 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 180 (245)/4,500-6,500 |
| Engine torque (Nm) at 1/min | 400/1,600-4,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 5.7 |
| Combined in l/100 km | 7.7-6.9 |
|---|---|
| CO2 combined emissions in g/km | 176-157 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,770 |
|---|---|
| Max. permissible weight in kg | 2,190 |
| Permitted load in kg | 495 |
| Permitted axle load front/rear in kg | 1,070/1,180 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 275 (374)/5,500-6,500 |
| Engine torque (Nm) at 1/min | 500/1,900-5,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.8 |
| Combined in l/100 km | 8.1-7.4 |
|---|---|
| CO2 combined emissions in g/km | 184-167 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/45 R18 95 Y XL |
|---|---|
| Tyre dimensions rear | 255/40 R18 99 Y XL |
| Wheel dimensions and material front | 7.5 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 18 inches, light-alloy |
| Unladen weight EU in kg | 1,815 |
|---|---|
| Max. permissible weight in kg | 2,245 |
| Permitted load in kg | 505 |
| Permitted axle load front/rear in kg | 1,110/1,190 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 6/4 |
|---|---|
| Capacity in ccm | 2,998 |
| Stroke/bore in mm | 94.6/82.0 |
| Engine power in kW (hp) at 1/min | 275 (374)/5,500-6,500 |
| Engine torque (Nm) at 1/min | 500/1,900-5,000 |
| Compression ratio : 1 | 10.2 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.5 |
| Combined in l/100 km | 8.2-7.4 |
|---|---|
| CO2 combined emissions in g/km | 186-170 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/45 R18 95 Y XL |
|---|---|
| Tyre dimensions rear | 255/40 R18 99 Y XL |
| Wheel dimensions and material front | 7.5 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 18 inches, light-alloy |
| Unladen weight EU in kg | 1,680 |
|---|---|
| Max. permissible weight in kg | 2,095 |
| Permitted load in kg | 490 |
| Permitted axle load front/rear in kg | 1,020/1,160 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,600 |
| Trailer load 12% (braked) in kg | 1,600 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 120-140 (163-190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 - 1,750-2,250 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 229-240 |
|---|---|
| Acceleration 0–100 km/h in s | 7.8-7.1 |
| Combined in l/100 km | 5.3-4.6 |
|---|---|
| CO2 combined emissions in g/km | 139-119 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1,745 |
|---|---|
| Max. permissible weight in kg | 2,165 |
| Permitted load in kg | 495 |
| Permitted axle load front/rear in kg | 1,070/1,170 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 1,995 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 140 (190)/4,000 |
| Engine torque (Nm) at 1/min | 400/1,750-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 238 |
|---|---|
| Acceleration 0–100 km/h in s | 7.4 |
| Combined in l/100 km | 5.6-4.9 |
|---|---|
| CO2 combined emissions in g/km | 147-129 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1.855 |
|---|---|
| Max. permissible weight in kg | 2.285 |
| Permitted load in kg | 505 |
| Permitted axle load front/rear in kg | 1,150/1,200 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 2.993 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 210 (286)/4,000 |
| Engine torque (Nm) at 1/min | 650/1,500-2,500 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 5.1 |
| Combined in l/100 km | 5.9-5.2 |
|---|---|
| CO2 combined emissions in g/km | 155-137 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/50 R17 98 Y XL |
|---|---|
| Tyre dimensions rear | 225/50 R17 98 Y XL |
| Wheel dimensions and material front | 7.5 J x 17 inches, light-alloy |
| Wheel dimensions and material rear | 7.5 J x 17 inches, light-alloy |
| Unladen weight EU in kg | 1.905 |
|---|---|
| Max. permissible weight in kg | 2,340 |
| Permitted load in kg | 510 |
| Permitted axle load front/rear in kg | 1,170/1,225 |
| Luggage capacity min. (seats up or roof down) in l | 440 |
| Luggage capacity max. (seats down or roof up) in l | - |
| Trailer load (unbraked) in kg | 750 |
| Trailer load 8% (braked) in kg | 1,800 |
| Trailer load 12% (braked) in kg | 1,800 |
| Cylinders/valves | 4/4 |
|---|---|
| Capacity in ccm | 2.993 |
| Stroke/bore in mm | 90.0/84.0 |
| Engine power in kW (hp) at 1/min | 250 (340)/4,400 |
| Engine torque (Nm) at 1/min | 700/1,750-2,250 |
| Compression ratio : 1 | 16.5 |
| Top speed in km/h | 250 |
|---|---|
| Acceleration 0–100 km/h in s | 4.6 |
| Combined in l/100 km | 6.3-5.7 |
|---|---|
| CO2 combined emissions in g/km | 165-150 |
| Tank capacity, approx. in l | 59 |
| Tyre dimensions front | 225/45 R18 95 Y XL |
|---|---|
| Tyre dimensions rear | 255/40 R18 99 Y XL |
| Wheel dimensions and material front | 7.5 J x 18 inches, light-alloy |
| Wheel dimensions and material rear | 8.5 J x 18 inches, light-alloy |
FUEL CONSUMPTION AND CO2 EMISSIONS.
BMW M440i xDrive Coupé:
Fuel consumption in l/100 km (combined): 8.5–8.0
CO2 emissions in g/km (combined): 194–181
Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.
At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.
