THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA.

Discover the powerful petrol and diesel engines as well as the dimensions and other technical data of the BMW 4 Series Coupé.

Read more
THE 4 THE BMW 4 SERIES COUPÉ: ENGINES & TECHNICAL DATA.

    TECHNICAL DATA OF THE BMW 4 SERIES COUPÉ.

    Weight

    Unladen weight EU in kg 1,600
    Max. permissible weight in kg 2,015
    Permitted load in kg 490
    Permitted axle load front/rear in kg 970/1,120
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,600
    Trailer load 12% (braked) in kg 1,600

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
    Engine torque (Nm) at 1/min 300/1,350-4,000
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 240
    Acceleration 0–100 km/h in s 7.5

    Fuel consumption

    Combined in l/100 km 7.1-6.3
    CO2 combined emissions in g/km 162-143
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,665
    Max. permissible weight in kg 1,080
    Permitted load in kg 490
    Permitted axle load front/rear in kg 1,020/1,130
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 135 (184)/5,000-6,500
    Engine torque (Nm) at 1/min 300/1,350-4,000
    Compression ratio : 1 11.0

    Performance

    Top speed in km/h 238
    Acceleration 0–100 km/h in s 7.8

    Fuel consumption

    Combined in l/100 km 7.5-6.6
    CO2 combined emissions in g/km 170-151
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,620
    Max. permissible weight in kg 2,030
    Permitted load in kg 485
    Permitted axle load front/rear in kg 980/1,120
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,600
    Trailer load 12% (braked) in kg 1,600

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 180 (245)/4,500-6,500
    Engine torque (Nm) at 1/min 400/1,600-4,000
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 5.9

    Fuel consumption

    Combined in l/100 km 7.4-6.6
    CO2 combined emissions in g/km 168-149
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,680
    Max. permissible weight in kg 2.095
    Permitted load in kg 490
    Permitted axle load front/rear in kg 1,030/1,130
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 180 (245)/4,500-6,500
    Engine torque (Nm) at 1/min 400/1,600-4,000
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 5.7

    Fuel consumption

    Combined in l/100 km 7.7-6.9
    CO2 combined emissions in g/km 176-157
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,770
    Max. permissible weight in kg 2,190
    Permitted load in kg 495
    Permitted axle load front/rear in kg 1,070/1,180
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 6/4
    Capacity in ccm 2,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
    Engine torque (Nm) at 1/min 500/1,900-5,000
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.8

    Fuel consumption

    Combined in l/100 km 8.1-7.4
    CO2 combined emissions in g/km 184-167
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/45 R18 95 Y XL
    Tyre dimensions rear 255/40 R18 99 Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,815
    Max. permissible weight in kg 2,245
    Permitted load in kg 505
    Permitted axle load front/rear in kg 1,110/1,190
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 6/4
    Capacity in ccm 2,998
    Stroke/bore in mm 94.6/82.0
    Engine power in kW (hp) at 1/min 275 (374)/5,500-6,500
    Engine torque (Nm) at 1/min 500/1,900-5,000
    Compression ratio : 1 10.2

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.5

    Fuel consumption

    Combined in l/100 km 8.2-7.4
    CO2 combined emissions in g/km 186-170
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/45 R18 95 Y XL
    Tyre dimensions rear 255/40 R18 99 Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,680
    Max. permissible weight in kg 2,095
    Permitted load in kg 490
    Permitted axle load front/rear in kg 1,020/1,160
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,600
    Trailer load 12% (braked) in kg 1,600

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power in kW (hp) at 1/min 120-140 (163-190)/4,000
    Engine torque (Nm) at 1/min 400/1,750-2,500 - 1,750-2,250
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 229-240
    Acceleration 0–100 km/h in s 7.8-7.1

    Fuel consumption

    Combined in l/100 km 5.3-4.6
    CO2 combined emissions in g/km 139-119
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1,745
    Max. permissible weight in kg 2,165
    Permitted load in kg 495
    Permitted axle load front/rear in kg 1,070/1,170
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 1,995
    Stroke/bore in mm 90.0/84.0
    Engine power in kW (hp) at 1/min 140 (190)/4,000
    Engine torque (Nm) at 1/min 400/1,750-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 238
    Acceleration 0–100 km/h in s 7.4

    Fuel consumption

    Combined in l/100 km 5.6-4.9
    CO2 combined emissions in g/km 147-129
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1.855
    Max. permissible weight in kg 2.285
    Permitted load in kg 505
    Permitted axle load front/rear in kg 1,150/1,200
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 2.993
    Stroke/bore in mm 90.0/84.0
    Engine power in kW (hp) at 1/min 210 (286)/4,000
    Engine torque (Nm) at 1/min 650/1,500-2,500
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 5.1

    Fuel consumption

    Combined in l/100 km 5.9-5.2
    CO2 combined emissions in g/km 155-137
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/50 R17 98 Y XL
    Tyre dimensions rear 225/50 R17 98 Y XL
    Wheel dimensions and material front 7.5 J x 17 inches, light-alloy
    Wheel dimensions and material rear 7.5 J x 17 inches, light-alloy

    Weight

    Unladen weight EU in kg 1.905
    Max. permissible weight in kg 2,340
    Permitted load in kg 510
    Permitted axle load front/rear in kg 1,170/1,225
    Luggage capacity min. (seats up or roof down) in l 440
    Luggage capacity max. (seats down or roof up) in l -
    Trailer load (unbraked) in kg 750
    Trailer load 8% (braked) in kg 1,800
    Trailer load 12% (braked) in kg 1,800

    Engine

    Cylinders/valves 4/4
    Capacity in ccm 2.993
    Stroke/bore in mm 90.0/84.0
    Engine power in kW (hp) at 1/min 250 (340)/4,400
    Engine torque (Nm) at 1/min 700/1,750-2,250
    Compression ratio : 1 16.5

    Performance

    Top speed in km/h 250
    Acceleration 0–100 km/h in s 4.6

    Fuel consumption

    Combined in l/100 km 6.3-5.7
    CO2 combined emissions in g/km 165-150
    Tank capacity, approx. in l 59

    Wheels

    Tyre dimensions front 225/45 R18 95 Y XL
    Tyre dimensions rear 255/40 R18 99 Y XL
    Wheel dimensions and material front 7.5 J x 18 inches, light-alloy
    Wheel dimensions and material rear 8.5 J x 18 inches, light-alloy
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

    FUEL CONSUMPTION AND CO2 EMISSIONS.

    BMW M440i xDrive Coupé:
    Fuel consumption in l/100 km (combined): 8.5–8.0
    CO2 emissions in g/km (combined): 194–181



    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp

    Read more
    • For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.


      At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.
