bmw 3 series touring engines and dimensions

THE 3

BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

THE 3BMW 3 SERIES TOURING: ENGINES & TECHNICAL DATA

    TECHNICAL DATA.

    System Power

    System power in kW (hp) 215 (292)
    Max. Torque (Nm) 420

    BMW eDrive

    Electric power 83 / 113
    Max. torque (Nm) at 1/min 265

    Engine

    Cylinder/ Valves per cylinder 4 / 4
    Technical capacity in cm3 1,998
    Stroke/Drilling in mm 94.6 / 82
    Engine performance in kW (hp) 135 (184) / 5000-6500
    Max torque(Nm) per 1/min 300 / 1350-4000
    Compression:1 11

    Range Charging

    WLTP combined electric range in miles 36 - 37
    Battery type Li-Ion
    Battery capacity 11.15
    Charging duration AC 2.6
    Charging duration in hrs (wallbox / public charging with max 3.7kW, 0-100%) 3.6
    Charging duration in hrs (household socket 230V / 12.5A, 0-80%) 4.3
    Charging duration in hrs (household socket 230V / 12.5A, 0-100%) 6

    Performance

    Top Speed 142
    Top Speed Electric 86
    Acceleration 5.9

    Measurements

    Length/Width/Height 4,709 / 1,827 / 1,442
    Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
    Wheelbase in mm/Wheel turn in m 2,851 / 11.4
    Ground clearance in mm 139
    Measurements
    Measurements

    Weight

    Weight not loaded in kg 1,905
    Weight Max in kg 2,355
    Permitted load in kg 525
    Permitted Axle load front/rear in kg 1,050 / 1,380
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Allowed braked trailer load up to 12 % / 8 % incline in kg 1,500 / 1,500
    Trunk capacity min.-max. in l 410 - 1420

    Wheels

    Tire front 225/50 R17 98 Y XL
    Tire rear 225/50 R17 98 Y XL
    Rim front 7,5Jx17 LM
    Rim rear 7,5Jx17 LM

    Consumption

    Electricity consumption combined in mi/kWh 2.9
    Fuel consumption Weighted 201.8 - 188.3
    Electric consumption AC Weighted 3.8 - 3.7
    Tank capacity in l 40

    CO2 Emissions

    CO2 weighted 32 - 33

    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
