    BMW 4 Series Gran Coupé

    TECHNICAL DATA OF THE ALL-NEW BMW 4 SERIES GRAN COUPÉ.

    System Power

    Fuel type Electric
    Power in kW (hp) 250 (340)
    Torque in Nm 430
    Gearbox 1-speed, automatic
    Drivetrain Rear-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 105 (143)
    Max. Torque (Nm) 430

    Range Charging

    Electric range, WLTP in miles 336 - 352
    Maximum Charging Performance 11
    AC charging time in h (0-100% state of charge) with wallbox 8.5
    Maximum DC charging performance in kW 205
    DC charging time in min (10-80% state of charge) with High-Power-Charging Station 31

    Performance

    Maximum speed in mph 118
    Acceleration 0–62 mph in s 5.6

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,448
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12.5
    Ground clearance in mm 125
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 2,125
    Weight max in kg 2,605
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,140 / 1,550
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/35 R20 95 Y XL
    Tire rear 255/35 R20 100 Y
    Rim front 8,5Jx20 LM
    Rim rear 9Jx20 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.7 - 3.5

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 400 (544)
    Torque in Nm 795
    Gearbox 1-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 125 (170)
    Max. Torque (Nm) 795

    Range Charging

    Electric range, WLTP in miles 257 - 318
    Maximum Charging Performance 11
    AC charging time in h (0-100% state of charge) with wallbox 8.5
    Maximum DC charging performance in kW 205
    DC charging time in min (10-80% state of charge) with High-Power-Charging Station 31

    Performance

    Maximum speed in mph 139
    Acceleration 0–62 mph in s 3.9

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,448
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12.5
    Ground clearance in mm 125
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 2,290
    Weight max in kg 2,735
    Permitted load in kg 520
    Permitted Axle load front/rear in kg 1,270 / 1,550
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/45 R18 100 Y XL
    Tire rear 255/45 R18 103 Y XL
    Rim front 8,5Jx18 LM
    Rim rear 9Jx18 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.4 - 2.8

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 250 (340)
    Torque in Nm 430
    Gearbox 1-speed, automatic
    Drivetrain Rear-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 105 (143)
    Max. Torque (Nm) 430

    Range Charging

    Electric range, WLTP in miles 346 - 365
    Maximum Charging Performance 11
    AC charging time in h (0-100% state of charge) with wallbox 8.5
    Maximum DC charging performance in kW 205
    DC charging time in min (10-80% state of charge) with High-Power-Charging Station 31

    Performance

    Maximum speed in mph 118
    Acceleration 0–62 mph in s 5.6

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,448
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12.5
    Ground clearance in mm 125
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 2,125
    Weight max in kg 2,605
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,140 / 1,550
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 225/55 R17 101 Y XL
    Tire rear 225/55 R17 101 Y XL
    Rim front 7,5Jx17 LM
    Rim rear 7,5Jx17 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.9 - 3.6

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 210 (286)
    Torque in Nm 400
    Gearbox 1-speed, automatic
    Drivetrain Rear-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 80 (109)
    Max. Torque (Nm) 400

    Range Charging

    Electric range, WLTP in miles 276 - 288
    Maximum Charging Performance 11
    AC charging time in h (0-100% state of charge) with wallbox 7
    Maximum DC charging performance in kW 180
    DC charging time in min (10-80% state of charge) with High-Power-Charging Station 32

    Performance

    Maximum speed in mph 118
    Acceleration 0–62 mph in s 6

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,448
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12.5
    Ground clearance in mm 125
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 2,065
    Weight max in kg 2,545
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,140 / 1,525
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/35 R20 95 Y XL
    Tire rear 255/35 R20 100 Y
    Rim front 8,5Jx20 LM
    Rim rear 9Jx20 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.8 - 3.6

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 210 (286)
    Torque in Nm 400
    Gearbox 1-speed, automatic
    Drivetrain Rear-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 80 (109)
    Max. Torque (Nm) 400

    Range Charging

    Electric range, WLTP in miles 284 - 299
    Maximum Charging Performance 11
    AC charging time in h (0-100% state of charge) with wallbox 7
    Maximum DC charging performance in kW 180
    DC charging time in min (10-80% state of charge) with High-Power-Charging Station 32

    Performance

    Maximum speed in mph 118
    Acceleration 0–62 mph in s 6

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,448
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12.5
    Ground clearance in mm 125
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 2,065
    Weight max in kg 2,545
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,140 / 1,525
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 225/55 R17 101 Y XL
    Tire rear 225/55 R17 101 Y XL
    Rim front 7,5Jx17 LM
    Rim rear 7,5Jx17 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.9 - 3.7

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Petrol
    Power in kW (hp) 135 (184)
    Torque in Nm 300
    Gearbox 8-speed, automatic
    Drivetrain Rear-wheel drive

    Engine

    Cylinder/ Valves per cylinder 4 / 4
    Displacement in cm³ 1,998
    Engine performance in kW (hp) 135 (184) / 5000 - 6500
    Max torque(Nm) per 1/min 300 / 1350 - 4000

    Performance

    Maximum speed in mph 146
    Acceleration 0–62 mph in s 7.9

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,442
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12
    Ground clearance in mm 140
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 1,695
    Weight max in kg 2,175
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,015 / 1,245
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/35 R20 95 Y XL
    Tire rear 255/35 R20 97 Y XL
    Rim front 8,5Jx20 LM
    Rim rear 9Jx20 LM

    Consumption

    Fuel consumption, combined WLTP in mpg 41.5 - 39.2
    Fuel capacity in l 59

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 154 - 163

    System Power

    Fuel type Petrol
    Power in kW (hp) 135 (184)
    Torque in Nm 300
    Gearbox 8-speed, automatic
    Drivetrain Rear-wheel drive

    Engine

    Cylinder/ Valves per cylinder 4 / 4
    Displacement in cm³ 1,998
    Engine performance in kW (hp) 135 (184) / 5000 - 6500
    Max torque(Nm) per 1/min 300 / 1350 - 4000

    Performance

    Maximum speed in mph 146
    Acceleration 0–62 mph in s 7.9

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,442
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12
    Ground clearance in mm 140
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 1,695
    Weight max in kg 2,175
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,015 / 1,245
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/35 R20 95 Y XL
    Tire rear 255/35 R20 97 Y XL
    Rim front 8,5Jx20 LM
    Rim rear 9Jx20 LM

    Consumption

    Fuel consumption, combined WLTP in mpg 41.5 - 39.2
    Fuel capacity in l 59

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 154 - 163

    System Power

    Fuel type Petrol – 48 Volt Mild-Hybrid
    Power in kW (hp) 275 (374)
    Torque in Nm 500
    Gearbox 8-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Electric power 8 (11)
    Max. Torque (Nm) 25

    Engine

    Cylinder/ Valves per cylinder 6 / 4
    Displacement in cm³ 2,998
    Engine performance in kW (hp) 275 (374) / 5500 - 6500
    Max torque(Nm) per 1/min 500 / 1900 - 5000

    Performance

    Maximum speed in mph 155
    Acceleration 0–62 mph in s 4.7

    Measurements

    Length/Width/Height 4,783 / 1,852 / 1,442
    Width incl. mirrors (driver / passenger side) in mm 2073 (1042 / 1031)
    Wheelbase in mm 2,856 / 12
    Ground clearance in mm 140
    BMW 4 Series Gran Coupé G26 technical data sketch
    BMW 4 Series Gran Coupé G26 technical data sketch

    Weight

    Weight not loaded in kg 1,900
    Weight max in kg 2,380
    Permitted load in kg 555
    Permitted Axle load front/rear in kg 1,145 / 1,325
    Allowed unbraked trailer load / drawbar load in kg 750 / 75
    Luggage capacity in l 470 - 1290

    Wheels

    Tire front 245/45 R18 100 Y XL
    Tire rear 245/45 R18 100 Y XL
    Rim front 8,5Jx18 LM
    Rim rear 8,5Jx18 LM

    Consumption

    Fuel Consumption charge sustaining combined 35.3 - 34
    Fuel capacity in l 59

    CO2 Emissions

    CO2 charge sustaining combined 182 - 190
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

    Fuel consumption and CO2 emissions of the BMW 4 Series Gran Coupé.

    BMW M440i xDrive Gran Coupé:
    Fuel consumption in l/100 km (combined): 8.5–8.0
    CO2 emissions in g/km (combined): 194–181

    Official data on fuel consumption and CO2 emissions were determined in accordance with the mandatory measurement procedure and comply with Regulation (EU) 715/2007 valid at the time of type approval. In case of a range, figures in the WLTP take into account any optional equipment. For newly type-tested vehicles since 01.01.2021, the official data no longer exist according to NEDC, but only according to WLTP. For more information on the WLTP and NEDC measurement procedures, see www.bmw.de/wltp.

    Read more
    ​

    • For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.


      At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.
