THE NEW BMW 3 SERIES TOURING: DIMENSIONS, ENGINES & SPECIFICATIONS.

THE NEW 3THE NEW BMW 3 SERIES TOURING: DIMENSIONS, ENGINES & SPECIFICATIONS.

The key facts and figures for the new BMW 3 Series Touring at a glance:


  • Engines, consumption and CO2 emissions
  • Performance data such as displacement, hp, Nm and acceleration
  • Weight, dimensions, wheel and tyre sizes
Read more

TECHNICAL DATA OF THE NEW BMW 3 SERIES TOURING.

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 215 (292) "1"
Torque in Nm 420 "1"
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

BMW eDrive

technicaldata.row.electricPower 80 (109)
Max. Torque (Nm) 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Range Charging

Electric range, WLTP in miles 34

Performance

Maximum speed in mph 143
Top Speed Electric 87
Acceleration 0–62 mph in s 5.9

Measurements

Length/Width/Height 4,713 / 1,827 / 1,442
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 139

Weight

Weight not loaded in kg 1,900
Weight max in kg 2,350
Permitted load in kg 525
Permitted Axle load front/rear in kg 1,050 / 1,380
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 410 - 1420

Wheels

Tire front 225/50 R17 98 Y XL
Tire rear 225/50 R17 98 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Fuel consumption Weighted 188.3
Electric consumption AC Weighted 3.3
Fuel capacity in l 40

CO2 Emissions

CO2 weighted 33 - 35

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 215 (292) "1"
Torque in Nm 420 "1"
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

technicaldata.row.electricPower 80 (109)
Max. Torque (Nm) 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Range Charging

Electric range, WLTP in miles 31 - 32

Performance

Maximum speed in mph 140
Top Speed Electric 87
Acceleration 0–62 mph in s 5.9

Measurements

Length/Width/Height 4,713 / 1,827 / 1,442
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 12
Ground clearance in mm 139

Weight

Weight not loaded in kg 1,955
Weight max in kg 2,405
Permitted load in kg 525
Permitted Axle load front/rear in kg 1,100 / 1,390
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 410 - 1420

Wheels

Tire front 225/50 R17 98 Y XL
Tire rear 225/50 R17 98 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Fuel consumption Weighted 176.6 - 166.2
Electric consumption AC Weighted 3.2
Fuel capacity in l 40

CO2 Emissions

CO2 weighted 37 - 38

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 215 (292) "1"
Torque in Nm 420 "1"
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

BMW eDrive

technicaldata.row.electricPower 80 (109)
Max. Torque (Nm) 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Range Charging

Electric range, WLTP in miles 32 - 34

Performance

Maximum speed in mph 143
Top Speed Electric 87
Acceleration 0–62 mph in s 5.9

Measurements

Length/Width/Height 4,713 / 1,827 / 1,442
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 139

Weight

Weight not loaded in kg 1,900
Weight max in kg 2,350
Permitted load in kg 525
Permitted Axle load front/rear in kg 1,050 / 1,380
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 410 - 1420

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel consumption Weighted 188.3 - 166.2
Electric consumption AC Weighted 3.3 - 3.1
Fuel capacity in l 40

CO2 Emissions

CO2 weighted 33 - 39

System Power

Fuel type Driving electric and with petrol
Power in kW (hp) 215 (292) "1"
Torque in Nm 420 "1"
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

technicaldata.row.electricPower 80 (109)
Max. Torque (Nm) 265

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Range Charging

Electric range, WLTP in miles 29 - 31

Performance

Maximum speed in mph 140
Top Speed Electric 87
Acceleration 0–62 mph in s 5.9

Measurements

Length/Width/Height 4,713 / 1,827 / 1,442
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 12
Ground clearance in mm 139

Weight

Weight not loaded in kg 1,955
Weight max in kg 2,405
Permitted load in kg 525
Permitted Axle load front/rear in kg 1,100 / 1,390
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 410 - 1420

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel consumption Weighted 166.2 - 141.2
Electric consumption AC Weighted 3.2 - 3
Fuel capacity in l 40

CO2 Emissions

CO2 weighted 37 - 45

System Power

Fuel type Petrol
Power in kW (hp) 135 (184)
Torque in Nm 300
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Performance

Maximum speed in mph 143
Acceleration 0–62 mph in s 7.6

Measurements

Length/Width/Height 4,713 / 1,827 / 1,440
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 141

Weight

Weight not loaded in kg 1,660
Weight max in kg 2,180
Permitted load in kg 595
Permitted Axle load front/rear in kg 975 / 1,285
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/50 R17 98 Y XL
Tire rear 225/50 R17 98 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Fuel consumption, combined WLTP in mpg 41.5 - 40.9
Fuel capacity in l 59

CO2 Emissions

CO2 emissions, combined WLTP in g/km 153 - 156

System Power

Fuel type Petrol
Power in kW (hp) 135 (184)
Torque in Nm 300
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,998
Engine performance in kW (hp) 135 (184) / 5000 - 6500
Max torque(Nm) per 1/min 300 / 1350 - 4000

Performance

Maximum speed in mph 143
Acceleration 0–62 mph in s 7.6

Measurements

Length/Width/Height 4,713 / 1,827 / 1,440
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 141

Weight

Weight not loaded in kg 1,660
Weight max in kg 2,180
Permitted load in kg 595
Permitted Axle load front/rear in kg 975 / 1,285
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel consumption, combined WLTP in mpg 41.5 - 39.2
Fuel capacity in l 59

CO2 Emissions

CO2 emissions, combined WLTP in g/km 153 - 162

System Power

Fuel type Petrol – 48 Volt Mild-Hybrid
Power in kW (hp) 275 (374)
Torque in Nm 500
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

technicaldata.row.electricPower 8 (11)
Max. Torque (Nm) 25

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,998
Engine performance in kW (hp) 275 (374) / 5500 - 6500
Max torque(Nm) per 1/min 500 / 1900 - 5000

Performance

Maximum speed in mph 155
Acceleration 0–62 mph in s 4.6

Measurements

Length/Width/Height 4,714 / 1,827 / 1,440
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 12
Ground clearance in mm 130

Weight

Weight not loaded in kg 1,870
Weight max in kg 2,390
Permitted load in kg 595
Permitted Axle load front/rear in kg 1,115 / 1,350
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/45 R18 95 Y XL
Tire rear 255/40 R18 99 Y XL
Rim front 7,5Jx18 LM
Rim rear 8,5Jx18 LM

Consumption

Fuel Consumption charge sustaining combined 34 - 33.6
Fuel capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 187 - 190

System Power

Fuel type Diesel – 48 Volt Mild-Hybrid
Power in kW (hp) 140 (190)
Torque in Nm 400
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

BMW eDrive

technicaldata.row.electricPower 8 (11)
Max. Torque (Nm) 25

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Maximum speed in mph 142
Acceleration 0–62 mph in s 7.2

Measurements

Length/Width/Height 4,713 / 1,827 / 1,440
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 141

Weight

Weight not loaded in kg 1,740
Weight max in kg 2,230
Permitted load in kg 565
Permitted Axle load front/rear in kg 1,010 / 1,315
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/50 R17 98 Y XL
Tire rear 225/50 R17 98 Y XL
Rim front 7,5Jx17 LM
Rim rear 7,5Jx17 LM

Consumption

Fuel Consumption charge sustaining combined 55.4 - 54.3
Fuel capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 134 - 137

System Power

Fuel type Diesel – 48 Volt Mild-Hybrid
Power in kW (hp) 140 (190)
Torque in Nm 400
Gearbox 8-speed, automatic
Drivetrain Rear-wheel drive

BMW eDrive

technicaldata.row.electricPower 8 (11)
Max. Torque (Nm) 25

Engine

Cylinder/ Valves per cylinder 4 / 4
Displacement in cm³ 1,995
Engine performance in kW (hp) 140 (190) / 4,000
Max torque(Nm) per 1/min 400 / 1750 - 2500

Performance

Maximum speed in mph 142
Acceleration 0–62 mph in s 7.2

Measurements

Length/Width/Height 4,713 / 1,827 / 1,440
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 11.4
Ground clearance in mm 141

Weight

Weight not loaded in kg 1,740
Weight max in kg 2,230
Permitted load in kg 565
Permitted Axle load front/rear in kg 1,010 / 1,315
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/40 R19 93 Y XL
Tire rear 255/35 R19 96 Y XL
Rim front 8Jx19 LM
Rim rear 8,5Jx19 LM

Consumption

Fuel Consumption charge sustaining combined 54.3 - 51.4
Fuel capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 135 - 145

System Power

Fuel type Diesel – 48 Volt Mild-Hybrid
Power in kW (hp) 250 (340)
Torque in Nm 700
Gearbox 8-speed, automatic
Drivetrain All-wheel drive

BMW eDrive

technicaldata.row.electricPower 8 (11)
Max. Torque (Nm) 25

Engine

Cylinder/ Valves per cylinder 6 / 4
Displacement in cm³ 2,993
Engine performance in kW (hp) 250 (340) / 4,400
Max torque(Nm) per 1/min 700 / 1750 - 2250

Performance

Maximum speed in mph 155
Acceleration 0–62 mph in s 4.7

Measurements

Length/Width/Height 4,713 / 1,827 / 1,445
Width incl. mirrors (driver / passenger side) in mm 2068 (1040 / 1028)
Wheelbase in mm 2,851 / 12
Ground clearance in mm 135

Weight

Weight not loaded in kg 1,945
Weight max in kg 2,430
Permitted load in kg 560
Permitted Axle load front/rear in kg 1,160 / 1,360
Allowed unbraked trailer load / drawbar load in kg 750 / 75
Luggage capacity in l 500 - 1510

Wheels

Tire front 225/45 R18 95 Y XL
Tire rear 255/40 R18 99 Y XL
Rim front 7,5Jx18 LM
Rim rear 8,5Jx18 LM

Consumption

Fuel Consumption charge sustaining combined 45.6 - 44.8
Fuel capacity in l 59

CO2 Emissions

CO2 charge sustaining combined 163 - 165
BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

For Plug-in Hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in Hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.

Read more
  • For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.


    At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.
