      BMW M5 Competition

      ENGINES & TECHNICAL DATA.

      Select Model
      Select Transmission

      System Power

      Fuel type Petrol
      System power in kW (hp) 390 (530)
      Max. Torque (Nm) 750
      Gearbox Automatic, 8-speed
      Drive Type all wheel drive

      Engine

      Cylinder/ Valves per cylinder 8 / 4
      Technical capacity in cm3 4,395
      Engine performance in kW (hp) 390 (530) / 5500 - 6000
      Max torque(Nm) per 1/min 750 / 1800 - 4600

      Performance

      Top Speed 155
      Acceleration 3.8

      Measurements

      Length/Width/Height 4,972 / 1,868 / 1,467
      Width incl. mirrors (driver / passenger side) in mm 2126 (1069 / 1057)
      Wheelbase in mm/Wheel turn in m 2,975 / 12.4
      Ground clearance in mm 131
      Measurements
      Measurements

      Weight

      Weight not loaded in kg 1,990
      Weight Max in kg 2,560
      Permitted load in kg 645
      Permitted Axle load front/rear in kg 1,260 / 1,365
      Allowed unbraked trailer load / drawbar load in kg 750 / 90
      Allowed braked trailer load up to 12 % / 8 % incline in kg 2,000 / 2,000
      Trunk capacity min.-max. in l 530

      Wheels

      Tire front 245/40 R19 98 Y XL
      Tire rear 275/35 R19 100 Y XL
      Rim front 8Jx19 LM
      Rim rear 9Jx19 LM

      Consumption

      Combined in mpg 26.6 - 26.2
      Tank capacity in l 68

      CO2 Emissions

      Combined in g/km 243 - 247

      System Power

      Fuel type Petrol
      System power in kW (hp) 460 (625)
      Max. Torque (Nm) 750
      Gearbox Automatic, 8-speed
      Drive Type all wheel drive

      Engine

      Cylinder/ Valves per cylinder 8 / 4
      Technical capacity in cm3 4,395
      Engine performance in kW (hp) 460 (625) / 6,000
      Max torque(Nm) per 1/min 750 / 1800 - 5860

      Performance

      Top Speed 155
      Acceleration 3.3

      Measurements

      Length/Width/Height 4,983 / 1,903 / 1,469
      Width incl. mirrors (driver / passenger side) in mm 2126 (1069 / 1057)
      Wheelbase in mm/Wheel turn in m 2,982 / 12.6
      Ground clearance in mm 120
      Measurements
      Measurements

      Weight

      Weight not loaded in kg 1,970
      Weight Max in kg 2,440
      Permitted load in kg 545
      Permitted Axle load front/rear in kg 1,215 / 1,260
      Allowed unbraked trailer load / drawbar load in kg 750 / 90
      Allowed braked trailer load up to 12 % / 8 % incline in kg 2,000 / 2,000
      Trunk capacity min.-max. in l 530

      Wheels

      Tire front 275/35 ZR20 (102Y) XL
      Tire rear 285/35 ZR20 (104Y) XL
      Rim front 9,5J x 20
      Rim rear 10,5J x 20

      Consumption

      Combined in mpg 25.4 - 25
      Tank capacity in l 68

      CO2 Emissions

      Combined in g/km 254 - 258
