THE M3

THE NEW BMW 3 SERIES SALOON M MODELS: ENGINES & TECHNICAL DATA.
THE M3THE NEW BMW 3 SERIES SALOON M MODELS: ENGINES & TECHNICAL DATA.
The new BMW 3 Series Saloon M Models – engines, facts and dimensions.
BMW 3 SERIES SALOON M MODELS: TECHNICAL DATA.
Select model
- Diesel
- M340d xDrive Saloon
No search result found. Please try another input
Select transmission
Fuel type | Petrol |
---|---|
Power in kW (hp) | 375 (510) |
Torque in Nm | 650 |
Gearbox | 8-speed, automatic |
Drivetrain | Rear-wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Maximum speed in mph | 155 |
---|---|
Acceleration 0–62 mph in s | 3.9 |
Length/Width/Height | 4,794 / 1,903 / 1,433 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,857 / 12.2 |
Ground clearance in mm | 120 |
Weight not loaded in kg | 1,805 |
---|---|
Weight max in kg | 2,210 |
Permitted load in kg | 480 |
Permitted Axle load front/rear in kg | 1,080 / 1,180 |
Luggage capacity in l | 480 |
Tire front | 275/40 ZR18 (103Y) XL |
---|---|
Tire rear | 285/35 ZR19 (103Y) XL |
Rim front | 9,5Jx18 |
Rim rear | 10,5Jx19 |
Fuel consumption, combined WLTP in mpg | 28.8 |
---|---|
Fuel capacity in l | 59 |
CO2 emissions, combined WLTP in g/km | 223 - 224 |
---|
Fuel type | Petrol – 48 Volt Mild-Hybrid |
---|---|
Power in kW (hp) | 275 (374) |
Torque in Nm | 500 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Electric power | 8 (11) |
---|---|
Max. Torque (Nm) | 25 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,998 |
Engine performance in kW (hp) | 275 (374) / 5500 - 6500 |
Max torque(Nm) per 1/min | 500 / 1900 - 5000 |
Maximum speed in mph | 155 |
---|---|
Acceleration 0–62 mph in s | 4.4 |
Length/Width/Height | 4,714 / 1,827 / 1,440 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,851 / 12 |
Ground clearance in mm | 130 |
Weight not loaded in kg | 1,770 |
---|---|
Weight max in kg | 2,245 |
Permitted load in kg | 550 |
Permitted Axle load front/rear in kg | 1,115 / 1,230 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 75 |
Luggage capacity in l | 480 |
Tire front | 225/45 R18 95 Y XL |
---|---|
Tire rear | 255/40 R18 99 Y XL |
Rim front | 7,5Jx18 LM |
Rim rear | 8,5Jx18 LM |
Fuel Consumption charge sustaining combined | 34.9 - 34.4 |
---|---|
Fuel capacity in l | 59 |
CO2 charge sustaining combined | 182 - 184 |
---|
Fuel type | Petrol |
---|---|
Power in kW (hp) | 375 (510) |
Torque in Nm | 650 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 375 (510) / 6,250 |
Max torque(Nm) per 1/min | 650 / 2750 - 5500 |
Maximum speed in mph | 155 |
---|---|
Acceleration 0–62 mph in s | 3.5 |
Length/Width/Height | 4,794 / 1,903 / 1,434 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,857 / 12.6 |
Ground clearance in mm | 122 |
Weight not loaded in kg | 1,855 |
---|---|
Weight max in kg | 2,260 |
Permitted load in kg | 480 |
Permitted Axle load front/rear in kg | 1,125 / 1,200 |
Luggage capacity in l | 480 |
Tire front | 275/35 ZR19 (100Y) XL |
---|---|
Tire rear | 285/30 ZR20 (99Y) XL |
Rim front | 9,5Jx19 |
Rim rear | 10,5Jx20 |
Fuel consumption, combined WLTP in mpg | 28.2 - 28 |
---|---|
Fuel capacity in l | 59 |
CO2 emissions, combined WLTP in g/km | 228 - 230 |
---|
Fuel type | Diesel – 48 Volt Mild-Hybrid |
---|---|
Power in kW (hp) | 250 (340) |
Torque in Nm | 700 |
Gearbox | 8-speed, automatic |
Drivetrain | All-wheel drive |
Electric power | 8 (11) |
---|---|
Max. Torque (Nm) | 25 |
Cylinder/ Valves per cylinder | 6 / 4 |
---|---|
Displacement in cm³ | 2,993 |
Engine performance in kW (hp) | 250 (340) / 4,400 |
Max torque(Nm) per 1/min | 700 / 1750 - 2250 |
Maximum speed in mph | 155 |
---|---|
Acceleration 0–62 mph in s | 4.6 |
Length/Width/Height | 4,713 / 1,827 / 1,445 |
---|---|
Width incl. mirrors (driver / passenger side) in mm | 2068 (1040 / 1028) |
Wheelbase in mm | 2,851 / 12 |
Ground clearance in mm | 135 |
Weight not loaded in kg | 1,875 |
---|---|
Weight max in kg | 2,340 |
Permitted load in kg | 540 |
Permitted Axle load front/rear in kg | 1,155 / 1,260 |
Allowed unbraked trailer load / drawbar load in kg | 750 / 75 |
Luggage capacity in l | 480 |
Tire front | 225/45 R18 95 Y XL |
---|---|
Tire rear | 255/40 R18 99 Y XL |
Rim front | 7,5Jx18 LM |
Rim rear | 8,5Jx18 LM |
Fuel Consumption charge sustaining combined | 46.3 |
---|---|
Fuel capacity in l | 59 |
CO2 charge sustaining combined | 159 - 161 |
---|
Fuel consumption and CO2 emissions.
Figures shown are for comparability purposes; only compare fuel consumption and CO2 figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the accessories fitted (post-registration), variations in weather, driving styles and vehicle load.
