BMW 1 Series 128ti F40, three-quarter rear view driving

THE 1

BMW 1 SERIES: ENGINES & TECHNICAL DATA.

THE 1BMW 1 SERIES: ENGINES & TECHNICAL DATA.

BMW 1 SERIES: TECHNICAL DATA.

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.9

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,365
Weight max in kg	1,845
Permitted load in kg	555
Permitted Axle load front/rear in kg	980 / 940
Allowed unbraked trailer load / drawbar load in kg	680 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	49.6 - 47.9
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	130 - 135

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.8

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,395
Weight max in kg	1,870
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,005 / 940
Allowed unbraked trailer load / drawbar load in kg	695 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	49.6 - 47.9
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	129 - 135

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.9

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,365
Weight max in kg	1,845
Permitted load in kg	555
Permitted Axle load front/rear in kg	980 / 940
Allowed unbraked trailer load / drawbar load in kg	680 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	49.6 - 46.3
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	130 - 138

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.8

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,395
Weight max in kg	1,870
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,005 / 940
Allowed unbraked trailer load / drawbar load in kg	695 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	49.6 - 47.1
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	130 - 138

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.9

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,365
Weight max in kg	1,845
Permitted load in kg	555
Permitted Axle load front/rear in kg	980 / 940
Allowed unbraked trailer load / drawbar load in kg	680 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	235/35 R19 91 Y XL
Tire rear	235/35 R19 91 Y XL
Rim front	8Jx19 LM
Rim rear	8Jx19 LM

Consumption
Fuel consumption, combined WLTP in mpg	47.9 - 42.8
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	134 - 150

System Power
Fuel type	Petrol
Power in kW (hp)	100 (136)
Torque in Nm	220
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,499
Engine performance in kW (hp)	100 (136) / 4500 - 6500
Max torque(Nm) per 1/min	220 / 1500 - 4100

Performance
Maximum speed in mph	132
Acceleration 0–62 mph in s	8.8

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,395
Weight max in kg	1,870
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,005 / 940
Allowed unbraked trailer load / drawbar load in kg	695 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	235/35 R19 91 Y XL
Tire rear	235/35 R19 91 Y XL
Rim front	8Jx19 LM
Rim rear	8Jx19 LM

Consumption
Fuel consumption, combined WLTP in mpg	47.9 - 42.8
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	134 - 150

System Power
Fuel type	Petrol
Power in kW (hp)	195 (265)
Torque in Nm	400
Gearbox	8-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	4 / 4
Displacement in cm³	1,998
Engine performance in kW (hp)	195 (265) / 4750 - 6500
Max torque(Nm) per 1/min	400 / 1750 - 4500

Performance
Maximum speed in mph	155
Acceleration 0–62 mph in s	6.1

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,520
Weight max in kg	2,000
Permitted load in kg	555
Permitted Axle load front/rear in kg	1,085 / 990
Luggage capacity in l	380 - 1200

Wheels
Tire front	225/40 R18 92 Y XL
Tire rear	225/40 R18 92 Y XL
Rim front	8Jx18 LM
Rim rear	8Jx18 LM

Consumption
Fuel consumption, combined WLTP in mpg	40.9 - 38.2
Fuel capacity in l	50

CO2 Emissions
CO2 emissions, combined WLTP in g/km	157 - 170

System Power
Fuel type	Petrol
Power in kW (hp)	225 (306)
Torque in Nm	450
Gearbox	8-speed, automatic
Drivetrain	All-wheel drive

Engine
Cylinder/ Valves per cylinder	4 / 4
Displacement in cm³	1,998
Engine performance in kW (hp)	225 (306) / 5000 - 6250
Max torque(Nm) per 1/min	450 / 1800 - 4500

Performance
Maximum speed in mph	155
Acceleration 0–62 mph in s	4.8

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,600
Weight max in kg	2,085
Permitted load in kg	560
Permitted Axle load front/rear in kg	1,120 / 1,020
Luggage capacity in l	380 - 1200

Wheels
Tire front	225/40 R18 92 Y XL
Tire rear	225/40 R18 92 Y XL
Rim front	8Jx18 LM
Rim rear	8Jx18 LM

Consumption
Fuel consumption, combined WLTP in mpg	38.2 - 35.8
Fuel capacity in l	50

CO2 Emissions
CO2 emissions, combined WLTP in g/km	168 - 179

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.3

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,450
Weight max in kg	1,925
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,025 / 980
Allowed unbraked trailer load / drawbar load in kg	725 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	61.4 - 58.9
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	120 - 125

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.1

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,460
Weight max in kg	1,940
Permitted load in kg	555
Permitted Axle load front/rear in kg	1,040 / 980
Allowed unbraked trailer load / drawbar load in kg	730 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	61.4 - 58.9
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	121 - 126

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.3

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,450
Weight max in kg	1,925
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,025 / 980
Allowed unbraked trailer load / drawbar load in kg	725 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	61.4 - 57.6
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	121 - 128

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.1

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,460
Weight max in kg	1,940
Permitted load in kg	555
Permitted Axle load front/rear in kg	1,040 / 980
Allowed unbraked trailer load / drawbar load in kg	730 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	205/55 R16 91 W
Tire rear	205/55 R16 91 W
Rim front	7Jx16 LM
Rim rear	7Jx16 LM

Consumption
Fuel consumption, combined WLTP in mpg	60.1 - 57.6
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	122 - 129

System Power
Fuel type	Diesel
Power in kW (hp)	140 (190)
Torque in Nm	400
Gearbox	8-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	4 / 4
Displacement in cm³	1,995
Engine performance in kW (hp)	140 (190) / 4,000
Max torque(Nm) per 1/min	400 / 1750 - 2500

Performance
Maximum speed in mph	143
Acceleration 0–62 mph in s	7.3

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,525
Weight max in kg	2,000
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,085 / 985
Allowed unbraked trailer load / drawbar load in kg	750 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	225/45 R17 94 Y XL
Tire rear	225/45 R17 94 Y XL
Rim front	7,5Jx17 LM
Rim rear	7,5Jx17 LM

Consumption
Fuel consumption, combined WLTP in mpg	57.6 - 54.3
Fuel capacity in l	50

CO2 Emissions
CO2 emissions, combined WLTP in g/km	129 - 136

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	6-speed, manual
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.3

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,450
Weight max in kg	1,925
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,025 / 980
Allowed unbraked trailer load / drawbar load in kg	725 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	235/35 R19 91 Y XL
Tire rear	235/35 R19 91 Y XL
Rim front	8Jx19 LM
Rim rear	8Jx19 LM

Consumption
Fuel consumption, combined WLTP in mpg	58.9 - 53.3
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	124 - 139

System Power
Fuel type	Diesel
Power in kW (hp)	85 (116)
Torque in Nm	270
Gearbox	7-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	3 / 4
Displacement in cm³	1,496
Engine performance in kW (hp)	85 (116) / 4,000
Max torque(Nm) per 1/min	270 / 1750 - 2250

Performance
Maximum speed in mph	124
Acceleration 0–62 mph in s	10.1

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,460
Weight max in kg	1,940
Permitted load in kg	555
Permitted Axle load front/rear in kg	1,040 / 980
Allowed unbraked trailer load / drawbar load in kg	730 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	235/35 R19 91 Y XL
Tire rear	235/35 R19 91 Y XL
Rim front	8Jx19 LM
Rim rear	8Jx19 LM

Consumption
Fuel consumption, combined WLTP in mpg	58.9 - 53.3
Fuel capacity in l	42

CO2 Emissions
CO2 emissions, combined WLTP in g/km	125 - 140

System Power
Fuel type	Diesel
Power in kW (hp)	140 (190)
Torque in Nm	400
Gearbox	8-speed, automatic
Drivetrain	Front-wheel drive

Engine
Cylinder/ Valves per cylinder	4 / 4
Displacement in cm³	1,995
Engine performance in kW (hp)	140 (190) / 4,000
Max torque(Nm) per 1/min	400 / 1750 - 2500

Performance
Maximum speed in mph	143
Acceleration 0–62 mph in s	7.3

Measurements
Length/Width/Height	4,319 / 1,799 / 1,434
Width incl. mirrors (driver / passenger side) in mm	2081 (1045 / 1036)
Wheelbase in mm	2,670 / 11.4
Ground clearance in mm	153

Weight
Weight not loaded in kg	1,525
Weight max in kg	2,000
Permitted load in kg	550
Permitted Axle load front/rear in kg	1,085 / 985
Allowed unbraked trailer load / drawbar load in kg	750 / 75
Luggage capacity in l	380 - 1200

Wheels
Tire front	235/35 R19 91 Y XL
Tire rear	235/35 R19 91 Y XL
Rim front	8Jx19 LM
Rim rear	8Jx19 LM

Consumption
Fuel consumption, combined WLTP in mpg	55.4 - 50.4
Fuel capacity in l	50

CO2 Emissions
CO2 emissions, combined WLTP in g/km	133 - 146

BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Find out more

For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.

At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.

Download price list

Book a service

Visit the BMW Shop

Your browser is not up to date and may not be compatible with our website.

iX

iX

i7

i7

i5

i5

i5

i4

i4

iX3

iX2

iX1

Shop Online

Finance

Electromobility

Service & Workshop

Technology & Innovation

Parts & Accessories

Digital Services & Apps

Business & Corporate

Brand & Company

User Manuals & Support

Warranty & Recall

Culture & Sports

BMW Special sales

BMW 1 SERIES: ENGINES & TECHNICAL DATA.

BMW 1 SERIES: TECHNICAL DATA.

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements

Weight

Wheels

Consumption

CO2 Emissions

System Power

Engine

Performance

Measurements
