THE X3

THE BMW X3: ENGINES &
TECHNICAL DATA

THE X3THE BMW X3: ENGINES & <br> TECHNICAL DATA

TECHNICAL DATA OF THE BMW X3.

Select Model

Weight

Unladen weight EU in kg 2,010
Max. permissible weight in kg 2,550
Permitted load in kg 615
Permitted axle load front/rear in kg 1,220/1,415
Luggage capacity (seats up) in litres 550
Luggage capacity (seats down) in litres 1,600
Trailer load (unbraked) in kg 750
Trailer load 8% (braked) in kg 2,400-2,000
Trailer load 12% (braked) in kg 2,400-2,000

Engine

Cylinders/valves 6/4
Capacity in ccm 2,993
Stroke/bore in mm 90.0/84.0
Engine power in hp 286
Engine torque in Nm 650
Compression ratio : 1 16.5

Performance

Top speed in mph 146-152
Top speed electrical in mph -
Acceleration 0–62mph in seconds 5.9-5.7

Fuel consumption

WLTP Combined in mpg 7.0-6.2
WLTP CO2 combined emissions in g/km 184-162
Electricity consumption, combined miles/kWh -
Tank capacity, approx. in litres 68

Wheels

Tyre dimensions front 245/50 R 19
Tyre dimensions rear 245/50 R 19
Wheel dimensions front 7.5 J x 19 inches
Wheel dimensions rear 7.5 J x 19 inches

Range and charging

Electric range in miles -
Growth capacity of lithium–ion battery in kWh -
Charging time 3.7 kW/16 A, Wallbox (0-80 %) in hours -
Charging time 3.7 kW/16 A, Wallbox (0-100 %) hours -

Electric engine

Electric engine power in hp -
Electric Engine torque in NM -

Combined system power

Combined power in hp -
Combined torque in Nm -

BMW wheels and tyres EU tyre label close-up

BMW WHEELS & TYRES.

We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.

Fuel consumption and CO2 emissions of the BMW X3.

  • BMW X3 xDrive30e:
    Fuel consumption in l/100 km (combined): 2.6–2.0
    CO2 emissions in g/km (combined): 59–44

    BMW X3 xDrive30i:
    Fuel consumption in l/100 km (combined): 8.5–7.6
    CO2 emissions in g/km (combined): 194–173

    BMW X3 M40i:
    Fuel consumption in l/100 km (combined): 9.5–8.7
    CO2 emissions in g/km (combined): 217–199

    Official figures for fuel consumption, CO2 emissions, electricity consumption and electric range were determined in accordance with the prescribed measurement procedure and comply with Regulation (EU) 715/2007 as amended. WLTP figures take into account any optional equipment in the case of ranges. For vehicles newly type-approved since 01.01.2021, the official specifications exist only according to WLTP. Further information on the NEDC and WLTP measurement methods can be found at www.bmw.de/wltp
