BMW iX: DIMENSIONS, RANGE & SPECIFICATIONS.

THE iXBMW iX: DIMENSIONS, RANGE & SPECIFICATIONS.

    ENGINES AND TECHNICAL DATA OF THE BMW iX.

    Select model
    Select transmission

    System Power

    Fuel type Electric
    Power in kW (hp) 240 (326)
    Torque in Nm 630
    Gearbox 1-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 102 (139)
    Max. Torque (Nm) 630

    Range Charging

    Electric range, WLTP in miles 251 - 264

    Performance

    Maximum speed in mph 124
    Acceleration 0–62 mph in s 6.1

    Measurements

    Length/Width/Height 4,953 / 1,967 / 1,695
    Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
    Wheelbase in mm 3,000 / 12.8
    Ground clearance in mm 202
    BMW iX i20 technical data sketch
    BMW iX i20 technical data sketch

    Weight

    Weight not loaded in kg 2,440
    Weight max in kg 3,010
    Permitted load in kg 645
    Permitted Axle load front/rear in kg 1,450 / 1,690
    Allowed unbraked trailer load / drawbar load in kg 750 / 100
    Luggage capacity in l 500 - 1750

    Wheels

    Tire front 275/40 R22 107 Y XL
    Tire rear 275/40 R22 107 Y XL
    Rim front 9,5Jx22 LM
    Rim rear 9,5Jx22 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.1 - 2.9

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 385 (523)
    Torque in Nm 765
    Gearbox 1-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 140 (190)
    Max. Torque (Nm) 765

    Range Charging

    Electric range, WLTP in miles 365 - 383

    Performance

    Maximum speed in mph 124
    Acceleration 0–62 mph in s 4.6

    Measurements

    Length/Width/Height 4,953 / 1,967 / 1,695
    Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
    Wheelbase in mm 3,000 / 12.8
    Ground clearance in mm 202
    BMW iX i20 technical data sketch
    BMW iX i20 technical data sketch

    Weight

    Weight not loaded in kg 2,585
    Weight max in kg 3,145
    Permitted load in kg 635
    Permitted Axle load front/rear in kg 1,530 / 1,780
    Allowed unbraked trailer load / drawbar load in kg 750 / 100
    Luggage capacity in l 500 - 1750

    Wheels

    Tire front 275/40 R22 107 Y XL
    Tire rear 275/40 R22 107 Y XL
    Rim front 9,5Jx22 LM
    Rim rear 9,5Jx22 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.1 - 2.9

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 240 (326)
    Torque in Nm 630
    Gearbox 1-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 102 (139)
    Max. Torque (Nm) 630

    Range Charging

    Electric range, WLTP in miles 251 - 264

    Performance

    Maximum speed in mph 124
    Acceleration 0–62 mph in s 6.1

    Measurements

    Length/Width/Height 4,953 / 1,967 / 1,695
    Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
    Wheelbase in mm 3,000 / 12.8
    Ground clearance in mm 202
    BMW iX i20 technical data sketch
    BMW iX i20 technical data sketch

    Weight

    Weight not loaded in kg 2,440
    Weight max in kg 3,010
    Permitted load in kg 645
    Permitted Axle load front/rear in kg 1,450 / 1,690
    Allowed unbraked trailer load / drawbar load in kg 750 / 100
    Luggage capacity in l 500 - 1750

    Wheels

    Tire front 235/60 R20 108 H XL
    Tire rear 235/60 R20 108 H XL
    Rim front 8,5Jx20 LM
    Rim rear 8,5Jx20 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.1 - 2.9

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0

    System Power

    Fuel type Electric
    Power in kW (hp) 455 (619) "1"
    Torque in Nm 1015 "1"
    Gearbox 1-speed, automatic
    Drivetrain All-wheel drive

    BMW eDrive

    Engine performance in kW (hp) 140 (190)
    Max. Torque (Nm) 1,015

    Range Charging

    Electric range, WLTP in miles 338 - 348

    Performance

    Maximum speed in mph 155
    Acceleration 0–62 mph in s 3.8

    Measurements

    Length/Width/Height 4,953 / 1,967 / 1,696
    Width incl. mirrors (driver / passenger side) in mm 2230 (1118 / 1112)
    Wheelbase in mm 3,000 / 12.1
    Ground clearance in mm 203
    BMW iX i20 technical data sketch
    BMW iX i20 technical data sketch

    Weight

    Weight not loaded in kg 2,670
    Weight max in kg 3,160
    Permitted load in kg 565
    Permitted Axle load front/rear in kg 1,530 / 1,794
    Allowed unbraked trailer load / drawbar load in kg 750 / 100
    Luggage capacity in l 500 - 1750

    Wheels

    Tire front 255/50 R21 109 Y XL
    Tire rear 255/50 R21 109 Y XL
    Rim front 9Jx21 LM
    Rim rear 9Jx21 LM

    Consumption

    Electricity consumption combined in mi/kWh 2.8 - 2.7

    CO2 Emissions

    CO2 emissions, combined WLTP in g/km 0
    BMW wheels and tyres EU tyre label close-up

    BMW WHEELS & TYRES.

    We subject the tyres for our vehicles to stringent tests with up to 50 different quality criteria – significantly more than prescribed by the uniform tyre labelling regulation that applies throughout Europe. This is where you will find all the information on the properties of the tyres used at BMW.
    • For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles after the battery had been fully charged. Plug-in hybrid and battery electric vehicles require mains electricity for charging. Figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles and vehicle load.


      At temperatures below 0 degrees Celsius, purely electric driving mode of plug-in hybrid models will not be available until the battery has warmed up to an operational condition after the vehicle has travelled a few miles.
