BMW X1 technical data

BMW X1

BMW X1: TECHNICAL DATA

BMW X1BMW X1: TECHNICAL DATA
    BMW X1

    Here you can find the technical data of the BMW X1.

    Read more

    TECHNICAL DATA OF THE BMW X1.

    System Power

    System power in kW (hp) 162 (220)
    Max. Torque (Nm) 385

    BMW eDrive

    Electric power 70 / 95
    Max. torque (Nm) at 1/min 165

    Engine

    Cylinder/ Valves per cylinder 3 / 4
    Technical capacity in cm3 1,499
    Stroke/Drilling in mm 94.6 / 82
    Engine performance in kW (hp) 92 (125) / 5000-5500
    Max torque(Nm) per 1/min 220 / 1500-3800
    Compression:1 11

    Range Charging

    WLTP combined electric range in miles 31
    Battery type Li-Ion
    Battery capacity 8.82
    Charging duration AC 2.4
    Charging duration in hrs (wallbox / public charging with max 3.7kW, 0-100%) 3.2

    Performance

    Top Speed 119
    Top Speed Electric 83
    Acceleration 6.9

    Measurements

    Length/Width/Height 4,447 / 1,821 / 1,582
    Width incl. mirrors (driver / passenger side) in mm 2060 (1035 / 1025)
    Wheelbase in mm/Wheel turn in m 2,670 / 11.7
    Ground clearance in mm 147
    Measurements
    Measurements

    Weight

    Weight not loaded in kg 1,820
    Weight Max in kg 2,330
    Permitted load in kg 585
    Permitted Axle load front/rear in kg 1,110 / 1,270
    Allowed unbraked trailer load / drawbar load in kg 750 / 80
    Allowed braked trailer load up to 12 % / 8 % incline in kg 750 / 750
    Trunk capacity min.-max. in l 450 - 1470

    Wheels

    Tire front 225/55 R17 97 W
    Tire rear 225/55 R17 97 W
    Rim front 7,5Jx17 LM
    Rim rear 7,5Jx17 LM

    Consumption

    Electricity consumption combined in mi/kWh 3.1 - 3
    Fuel consumption Weighted 156.9 - 148.7
    Electric consumption AC Weighted 4.1
    Tank capacity in l 36

    CO2 Emissions

    CO2 weighted 41 - 43
